Public Member Functions
	Task (const std::string &name, Tasks::Context &ctx)

	~Task (void)

void	onResourceAcquisition (void)

void	onResourceRelease (void)

void	consume (const IMC::Pulse *msg)

int	parse (uint8_t byte)

void	sendMessage (uint8_t mid, const uint8_t *data, unsigned int data_len)

bool	sendMessageWithAck (uint8_t mid, const uint8_t *data, unsigned int data_len)

bool	sendGoToConfig (void)

bool	sendGoToMeasurement (void)

bool	sendSetOutputMode (void)

bool	sendSetOutputSettings (void)

bool	sendSyncInSettings (void)

bool	setup (void)

void	onMain (void)

Public Member Functions inherited from DUNE::Tasks::Task
	Task (const std::string &name, Context &context)

const char *	getName (void) const

const char *	getSystemName (void) const

unsigned int	getSystemId (void) const

unsigned int	getEntityId (void) const

unsigned int	resolveEntity (const std::string &label) const

std::string	resolveEntity (unsigned int id) const

DebugLevel	getDebugLevel (void) const

uint16_t	getActivationTime (void) const

uint16_t	getDeactivationTime (void) const

unsigned int	resolveSystemName (const std::string &name) const

const char *	resolveSystemId (unsigned int id) const

void	loadConfig (void)

void	setPriority (unsigned int value)

unsigned int	getPriority (void) const

void	inf (const char *format,...) DUNE_PRINTF_FORMAT(2

void void	war (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void	err (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void	cri (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void	debug (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void	trace (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void	spew (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void void	dispatch (IMC::Message *msg, unsigned int flags=0)

void	dispatch (IMC::Message &msg, unsigned int flags=0)

void	dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0)

void	receive (const IMC::Message *msg)

void	reserveEntities (void)

void	resolveEntities (void)

void	acquireResources (void)

void	releaseResources (void)

void	initializeResources (void)

void	updateParameters (bool act_deact=true)

void	writeParamsXML (std::ostream &os) const

const char *	getEntityLabel (void) const

void	setEntityLabel (const std::string &label)

Public Member Functions inherited from DUNE::Tasks::AbstractTask
	AbstractTask (void)

virtual	~AbstractTask (void)

Public Member Functions inherited from DUNE::Concurrency::Thread
	Thread (void)

virtual	~Thread (void)

int	getProcessorUsage (void)

Public Member Functions inherited from DUNE::Concurrency::Runnable
	Runnable (void)

virtual	~Runnable (void)

void	start (void)

void	stop (void)

void	join (void)

void	stopAndJoin (void)

void	setPriority (Scheduler::Policy policy, unsigned priority)

unsigned	getPriority (void)

State	getState (void)

bool	isCreated (void)

bool	isStopping (void)

bool	isRunning (void)

bool	isStarting (void)

bool	isDead (void)

Public Attributes
ParserStates	m_state

uint8_t	m_mid

uint8_t	m_data_len

uint8_t	m_data_idx

uint8_t	m_data [c_max_data_len]

unsigned int	m_csum

SerialPort *	m_uart

uint8_t *	m_bfr

IMC::EulerAngles	m_euler

IMC::Acceleration	m_accel

IMC::AngularVelocity	m_agvel

IMC::Temperature	m_temp

Arguments	m_args

Static Public Attributes
static const uint8_t	c_preamble

static const int	c_max_data_len

static const int	c_max_bfr_len

Additional Inherited Members
Public Types inherited from DUNE::Concurrency::Runnable
enum	State { StateStarting, StateRunning, StateStopping, StateDead, StateUnknown }

Protected Member Functions inherited from DUNE::Tasks::Task
void	setEntityState (IMC::EntityState::StateEnum state, Status::Code code)

void	setEntityState (IMC::EntityState::StateEnum state, const std::string &description)

IMC::EntityState::StateEnum	getEntityState (void) const

unsigned int	reserveEntity (const std::string &label)

template<typename E >
E *	reserveEntity (const std::string &label)

bool	stopping (void)

bool	isActive (void) const

bool	isActivating (void) const

bool	isDeactivating (void) const

void	waitForMessages (double timeout)

void	consumeMessages (void)

template<typename T >
Parameter &	param (const std::string &name, T &var)

template<typename Y , typename T >
Parameter &	param (const std::string &name, T &var)

template<typename T >
bool	paramChanged (T &var)

void	paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false)

void	setParamSectionEditor (const std::string &name)

template<typename M , typename T >
void	bind (T task_obj, void(T::consumer)(const M *)=&T::consume)

template<typename T >
void	bind (T *task_obj, const std::vector< uint32_t > &list)

template<typename T , typename M >
void	bind (T task_obj, const std::vector< uint32_t > &list, void(T::consumer)(const M *)=&T::consume)

template<typename T >
void	bind (T *task_obj, const std::vector< std::string > &list)

void	requestActivation (void)

void	requestDeactivation (void)

void	activate (void)

void	activationFailed (const std::string &reason)

void	deactivate (void)

void	deactivationFailed (const std::string &reason)

virtual bool	onWriteParamsXML (std::ostream &os) const

virtual void	onEntityReservation (void)

virtual void	onEntityResolution (void)

virtual void	onReportEntityState (void)

virtual void	onResourceInitialization (void)

virtual void	onUpdateParameters (void)

virtual void	onRequestActivation (void)

virtual void	onRequestDeactivation (void)

virtual void	onActivation (void)

virtual void	onDeactivation (void)

virtual void	onQueryEntityParameters (const IMC::QueryEntityParameters *msg)

virtual void	onSetEntityParameters (const IMC::SetEntityParameters *msg)

virtual void	onPushEntityParameters (const IMC::PushEntityParameters *msg)

virtual void	onPopEntityParameters (const IMC::PopEntityParameters *msg)

Protected Member Functions inherited from DUNE::Concurrency::Thread
void	startImpl (void)

void	stopImpl (void)

void	joinImpl (void)

void	setPriorityImpl (Scheduler::Policy policy, unsigned priority)

unsigned	getPriorityImpl (void)

Protected Attributes inherited from DUNE::Tasks::Task
Context &	m_ctx

std::vector < Entities::BasicEntity * >	m_entities

Constructor & Destructor Documentation

Sensors::MTi::Task::Task	(	const std::string &	name,
		Tasks::Context &	ctx
	)

inline

References c_max_bfr_len, DUNE::Tasks::Parameter::defaultValue(), m_args, m_bfr, DUNE::Tasks::Task::param(), Sensors::MTi::Arguments::uart_baud, and Sensors::MTi::Arguments::uart_dev.

Sensors::MTi::Task::~Task ( void )

inlinevirtual

Destructor.

Reimplemented from DUNE::Tasks::Task.

References m_bfr.

Member Function Documentation

void Sensors::MTi::Task::consume ( const IMC::Pulse * msg )

inline

References c_max_bfr_len, DUNE::Tasks::Task::dispatch(), m_accel, m_agvel, m_bfr, m_data, m_euler, m_temp, m_uart, parse(), and DUNE::Tasks::Task::war().

void Sensors::MTi::Task::onMain ( void )

inlinevirtual

Implements DUNE::Tasks::Task.

References m_uart, setup(), DUNE::Tasks::Task::stopping(), and DUNE::Tasks::Task::waitForMessages().

void Sensors::MTi::Task::onResourceAcquisition ( void )

inlinevirtual

Called when the task is instructed to acquire resources whose configuration is defined by run-time parameters.

Reimplemented from DUNE::Tasks::Task.

References m_args, m_uart, Sensors::MTi::Arguments::uart_baud, and Sensors::MTi::Arguments::uart_dev.

void Sensors::MTi::Task::onResourceRelease ( void )

inlinevirtual

Called when the task is instructed to release resources.

Derived classes that override this function must not assume that any resource was previously acquired. This function must be implemented in such a way that it can be called at any time.

Reimplemented from DUNE::Tasks::Task.

References m_uart.

int Sensors::MTi::Task::parse ( uint8_t byte )

inline

References c_preamble, DUNE::Tasks::Task::err(), m_csum, m_data, m_data_idx, m_data_len, m_mid, m_state, Sensors::MTi::PS_BID, Sensors::MTi::PS_CS, Sensors::MTi::PS_DATA, Sensors::MTi::PS_LEN, Sensors::MTi::PS_MID, and Sensors::MTi::PS_NONE.
