DUNE: Uniform Navigational Environment
2016.09.0
|
Public Member Functions | |
Task (const std::string &name, Tasks::Context &ctx) | |
void | onResourceAcquisition (void) |
void | onResourceRelease (void) |
void | consume (const IMC::PlanControl *pc) |
void | consume (const IMC::PowerOperation *po) |
void | consume (const IMC::PlanDB *req) |
void | onChange (const IMC::PlanDB &req) |
void | onChange (double time, uint16_t sid, const std::string &sname) |
void | setPlan (const IMC::PlanDB &req) |
void | storeInDB (const IMC::PlanSpecification *spec) |
void | deletePlan (const IMC::PlanDB &req) |
void | getPlan (const IMC::PlanDB &req) |
void | getPlanInfo (const IMC::PlanDB &req) |
void | clearDatabase (const IMC::PlanDB &req) |
void | getDatabaseState (const IMC::PlanDB &req) |
void | answer (uint8_t type, const char *desc) |
void | inProgress (const char *msg="in progress") |
void | onFailure (const char *errmsg) |
void | onSuccess (const char *msg=DTR("OK")) |
void | onMain (void) |
Public Member Functions inherited from DUNE::Tasks::Task | |
Task (const std::string &name, Context &context) | |
virtual | ~Task (void) |
const char * | getName (void) const |
const char * | getSystemName (void) const |
unsigned int | getSystemId (void) const |
unsigned int | getEntityId (void) const |
unsigned int | resolveEntity (const std::string &label) const |
std::string | resolveEntity (unsigned int id) const |
DebugLevel | getDebugLevel (void) const |
uint16_t | getActivationTime (void) const |
uint16_t | getDeactivationTime (void) const |
unsigned int | resolveSystemName (const std::string &name) const |
const char * | resolveSystemId (unsigned int id) const |
void | loadConfig (void) |
void | setPriority (unsigned int value) |
unsigned int | getPriority (void) const |
void | inf (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void | war (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void | err (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void | cri (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void | debug (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void | trace (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void void | spew (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void void void | dispatch (IMC::Message *msg, unsigned int flags=0) |
void | dispatch (IMC::Message &msg, unsigned int flags=0) |
void | dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0) |
void | receive (const IMC::Message *msg) |
void | reserveEntities (void) |
void | resolveEntities (void) |
void | acquireResources (void) |
void | releaseResources (void) |
void | initializeResources (void) |
void | updateParameters (bool act_deact=true) |
void | writeParamsXML (std::ostream &os) const |
const char * | getEntityLabel (void) const |
void | setEntityLabel (const std::string &label) |
Public Member Functions inherited from DUNE::Tasks::AbstractTask | |
AbstractTask (void) | |
virtual | ~AbstractTask (void) |
Public Member Functions inherited from DUNE::Concurrency::Thread | |
Thread (void) | |
virtual | ~Thread (void) |
int | getProcessorUsage (void) |
Public Member Functions inherited from DUNE::Concurrency::Runnable | |
Runnable (void) | |
virtual | ~Runnable (void) |
void | start (void) |
void | stop (void) |
void | join (void) |
void | stopAndJoin (void) |
void | setPriority (Scheduler::Policy policy, unsigned priority) |
unsigned | getPriority (void) |
State | getState (void) |
bool | isCreated (void) |
bool | isStopping (void) |
bool | isRunning (void) |
bool | isStarting (void) |
bool | isDead (void) |
Public Attributes | |
Arguments | m_args |
Database::Connection * | m_db |
IMC::PlanDB | m_reply |
IMC::PlanDBInformation | m_plan_info |
Database::Statement * | m_insert_plan_stmt |
Database::Statement * | m_delete_plan_stmt |
Database::Statement * | m_plan_iterator_stmt |
Database::Statement * | m_query_plan_stmt |
Database::Statement * | m_get_plan_stmt |
Database::Statement * | m_delete_all_plans_stmt |
Database::Statement * | m_lastchange_update_stmt |
Database::Statement * | m_lastchange_query_stmt |
uint16_t | m_local_reqid |
Additional Inherited Members | |
Public Types inherited from DUNE::Concurrency::Runnable | |
enum | State { StateStarting, StateRunning, StateStopping, StateDead, StateUnknown } |
Protected Member Functions inherited from DUNE::Tasks::Task | |
void | setEntityState (IMC::EntityState::StateEnum state, Status::Code code) |
void | setEntityState (IMC::EntityState::StateEnum state, const std::string &description) |
IMC::EntityState::StateEnum | getEntityState (void) const |
unsigned int | reserveEntity (const std::string &label) |
template<typename E > | |
E * | reserveEntity (const std::string &label) |
bool | stopping (void) |
bool | isActive (void) const |
bool | isActivating (void) const |
bool | isDeactivating (void) const |
void | waitForMessages (double timeout) |
void | consumeMessages (void) |
template<typename T > | |
Parameter & | param (const std::string &name, T &var) |
template<typename Y , typename T > | |
Parameter & | param (const std::string &name, T &var) |
template<typename T > | |
bool | paramChanged (T &var) |
void | paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false) |
void | setParamSectionEditor (const std::string &name) |
template<typename M , typename T > | |
void | bind (T *task_obj, void(T::*consumer)(const M *)=&T::consume) |
template<typename T > | |
void | bind (T *task_obj, const std::vector< uint32_t > &list) |
template<typename T , typename M > | |
void | bind (T *task_obj, const std::vector< uint32_t > &list, void(T::*consumer)(const M *)=&T::consume) |
template<typename T > | |
void | bind (T *task_obj, const std::vector< std::string > &list) |
void | requestActivation (void) |
void | requestDeactivation (void) |
void | activate (void) |
void | activationFailed (const std::string &reason) |
void | deactivate (void) |
void | deactivationFailed (const std::string &reason) |
virtual bool | onWriteParamsXML (std::ostream &os) const |
virtual void | onEntityReservation (void) |
virtual void | onEntityResolution (void) |
virtual void | onReportEntityState (void) |
virtual void | onResourceInitialization (void) |
virtual void | onUpdateParameters (void) |
virtual void | onRequestActivation (void) |
virtual void | onRequestDeactivation (void) |
virtual void | onActivation (void) |
virtual void | onDeactivation (void) |
virtual void | onQueryEntityParameters (const IMC::QueryEntityParameters *msg) |
virtual void | onSetEntityParameters (const IMC::SetEntityParameters *msg) |
virtual void | onPushEntityParameters (const IMC::PushEntityParameters *msg) |
virtual void | onPopEntityParameters (const IMC::PopEntityParameters *msg) |
Protected Member Functions inherited from DUNE::Concurrency::Thread | |
void | startImpl (void) |
void | stopImpl (void) |
void | joinImpl (void) |
void | setPriorityImpl (Scheduler::Policy policy, unsigned priority) |
unsigned | getPriorityImpl (void) |
Protected Attributes inherited from DUNE::Tasks::Task | |
Context & | m_ctx |
std::vector < Entities::BasicEntity * > | m_entities |
|
inline |
|
inline |
References DUNE::Tasks::Task::debug(), DUNE::Tasks::Task::dispatch(), DUNE::Tasks::Task::err(), DUNE::Tasks::Task::inf(), and m_reply.
Referenced by inProgress(), onFailure(), and onSuccess().
|
inline |
References inProgress(), m_db, m_delete_all_plans_stmt, onChange(), onFailure(), and onSuccess().
Referenced by consume().
|
inline |
References DUNE::Tasks::Task::getEntityId(), m_local_reqid, m_reply, storeInDB(), and DUNE::Tasks::Task::war().
|
inline |
|
inline |
References clearDatabase(), deletePlan(), getDatabaseState(), getPlan(), getPlanInfo(), m_db, m_reply, onFailure(), setPlan(), and DUNE::Tasks::Task::war().
|
inline |
References inProgress(), m_db, m_delete_plan_stmt, onChange(), onFailure(), and onSuccess().
Referenced by consume().
|
inline |
References m_lastchange_query_stmt, m_plan_iterator_stmt, m_reply, and onSuccess().
Referenced by consume().
|
inline |
References m_get_plan_stmt, m_reply, onFailure(), and onSuccess().
Referenced by consume().
|
inline |
References m_plan_info, m_query_plan_stmt, m_reply, onFailure(), and onSuccess().
Referenced by consume().
|
inline |
References answer().
Referenced by clearDatabase(), deletePlan(), onResourceAcquisition(), and setPlan().
|
inline |
References DUNE::Tasks::Task::resolveSystemId().
Referenced by clearDatabase(), deletePlan(), and storeInDB().
|
inline |
References m_lastchange_update_stmt.
|
inline |
References answer().
Referenced by clearDatabase(), consume(), deletePlan(), getPlan(), getPlanInfo(), setPlan(), and storeInDB().
|
inlinevirtual |
Implements DUNE::Tasks::Task.
References DUNE::Tasks::Task::stopping(), and DUNE::Tasks::Task::waitForMessages().
|
inlinevirtual |
Called when the task is instructed to acquire resources whose configuration is defined by run-time parameters.
Reimplemented from DUNE::Tasks::Task.
References Plan::DB::Arguments::db_path, DUNE::Tasks::Context::dir_db, DUNE::Tasks::Task::getSystemId(), DUNE::Tasks::Task::getSystemName(), DUNE::Tasks::Task::inf(), inProgress(), m_args, DUNE::Tasks::Task::m_ctx, m_db, m_delete_all_plans_stmt, m_delete_plan_stmt, m_get_plan_stmt, m_insert_plan_stmt, m_lastchange_query_stmt, m_lastchange_update_stmt, m_local_reqid, m_plan_iterator_stmt, m_query_plan_stmt, m_reply, onSuccess(), and DUNE::Tasks::Task::setEntityState().
Referenced by consume().
|
inlinevirtual |
Called when the task is instructed to release resources.
Derived classes that override this function must not assume that any resource was previously acquired. This function must be implemented in such a way that it can be called at any time.
Reimplemented from DUNE::Tasks::Task.
References m_db, m_delete_all_plans_stmt, m_delete_plan_stmt, m_get_plan_stmt, m_insert_plan_stmt, m_lastchange_query_stmt, m_lastchange_update_stmt, m_plan_iterator_stmt, and m_query_plan_stmt.
Referenced by consume().
|
inline |
References answer().
Referenced by clearDatabase(), deletePlan(), getDatabaseState(), getPlan(), getPlanInfo(), onResourceAcquisition(), and storeInDB().
|
inline |
References inProgress(), onFailure(), and storeInDB().
Referenced by consume().
|
inline |
References m_db, m_delete_plan_stmt, m_insert_plan_stmt, m_plan_info, m_reply, onChange(), onFailure(), onSuccess(), and DUNE::Tasks::Task::resolveSystemId().
Arguments Plan::DB::Task::m_args |
Referenced by onResourceAcquisition(), and Task().
Database::Connection* Plan::DB::Task::m_db |
Referenced by clearDatabase(), consume(), deletePlan(), onResourceAcquisition(), onResourceRelease(), and storeInDB().
Database::Statement* Plan::DB::Task::m_delete_all_plans_stmt |
Referenced by clearDatabase(), onResourceAcquisition(), and onResourceRelease().
Database::Statement* Plan::DB::Task::m_delete_plan_stmt |
Referenced by deletePlan(), onResourceAcquisition(), onResourceRelease(), and storeInDB().
Database::Statement* Plan::DB::Task::m_get_plan_stmt |
Referenced by getPlan(), onResourceAcquisition(), and onResourceRelease().
Database::Statement* Plan::DB::Task::m_insert_plan_stmt |
Referenced by onResourceAcquisition(), onResourceRelease(), and storeInDB().
Database::Statement* Plan::DB::Task::m_lastchange_query_stmt |
Referenced by getDatabaseState(), onResourceAcquisition(), and onResourceRelease().
Database::Statement* Plan::DB::Task::m_lastchange_update_stmt |
Referenced by onChange(), onResourceAcquisition(), and onResourceRelease().
uint16_t Plan::DB::Task::m_local_reqid |
Referenced by consume(), and onResourceAcquisition().
IMC::PlanDBInformation Plan::DB::Task::m_plan_info |
Referenced by getPlanInfo(), and storeInDB().
Database::Statement* Plan::DB::Task::m_plan_iterator_stmt |
Referenced by getDatabaseState(), onResourceAcquisition(), and onResourceRelease().
Database::Statement* Plan::DB::Task::m_query_plan_stmt |
Referenced by getPlanInfo(), onResourceAcquisition(), and onResourceRelease().
IMC::PlanDB Plan::DB::Task::m_reply |
Referenced by answer(), consume(), getDatabaseState(), getPlan(), getPlanInfo(), onResourceAcquisition(), and storeInDB().
