DUNE: Uniform Navigational Environment
2016.09.0
|
Relative State.
Public Member Functions | |
RelativeState (void) | |
Message * | clone (void) const |
void | clear (void) |
bool | fieldsEqual (const Message &msg__) const |
int | validate (void) const |
uint8_t * | serializeFields (uint8_t *bfr__) const |
uint16_t | deserializeFields (const uint8_t *bfr__, uint16_t size__) |
uint16_t | reverseDeserializeFields (const uint8_t *bfr__, uint16_t size__) |
uint16_t | getId (void) const |
const char * | getName (void) const |
unsigned | getFixedSerializationSize (void) const |
unsigned | getVariableSerializationSize (void) const |
void | fieldsToJSON (std::ostream &os__, unsigned nindent__) const |
Public Member Functions inherited from DUNE::IMC::Message | |
Message (void) | |
virtual | ~Message (void) |
double | setTimeStamp (double ts) |
double | setTimeStamp (void) |
double | getTimeStamp (void) const |
uint16_t | getSource (void) const |
void | setSource (uint16_t src) |
uint8_t | getSourceEntity (void) const |
void | setSourceEntity (uint8_t src_ent) |
uint16_t | getDestination (void) const |
void | setDestination (uint16_t dst) |
uint8_t | getDestinationEntity (void) const |
void | setDestinationEntity (uint8_t dst_ent) |
virtual uint16_t | getSubId (void) const |
virtual void | setSubId (uint16_t subid) |
virtual fp64_t | getValueFP (void) const |
virtual void | setValueFP (fp64_t val) |
unsigned | getSerializationSize (void) const |
unsigned | getPayloadSerializationSize (void) const |
void | toJSON (std::ostream &os) const |
void | toText (std::ostream &os) const |
bool | operator== (const Message &other) const |
bool | operator!= (const Message &other) const |
Static Public Member Functions | |
static uint16_t | getIdStatic (void) |
Public Attributes | |
std::string | s_id |
fp32_t | dist |
fp32_t | err |
fp32_t | ctrl_imp |
fp32_t | rel_dir_x |
fp32_t | rel_dir_y |
fp32_t | rel_dir_z |
fp32_t | err_x |
fp32_t | err_y |
fp32_t | err_z |
fp32_t | rf_err_x |
fp32_t | rf_err_y |
fp32_t | rf_err_z |
fp32_t | rf_err_vx |
fp32_t | rf_err_vy |
fp32_t | rf_err_vz |
fp32_t | ss_x |
fp32_t | ss_y |
fp32_t | ss_z |
fp32_t | virt_err_x |
fp32_t | virt_err_y |
fp32_t | virt_err_z |
Additional Inherited Members | |
Protected Member Functions inherited from DUNE::IMC::Message | |
virtual void | setTimeStampNested (double value) |
virtual void | setSourceNested (uint16_t value) |
virtual void | setSourceEntityNested (uint8_t value) |
virtual void | setDestinationNested (uint16_t value) |
virtual void | setDestinationEntityNested (uint8_t value) |
Protected Attributes inherited from DUNE::IMC::Message | |
Header | m_header |
DUNE::IMC::RelativeState::RelativeState | ( | void | ) |
References clear(), DUNE::IMC::Message::m_header, and DUNE::IMC::Header::mgid.
Referenced by clone().
|
virtual |
Reset message's fields.
Implements DUNE::IMC::Message.
References ctrl_imp, dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, ss_x, ss_y, ss_z, virt_err_x, virt_err_y, and virt_err_z.
Referenced by RelativeState().
|
inlinevirtual |
Retrieve a copy of the message.
Implements DUNE::IMC::Message.
References RelativeState().
|
virtual |
Deserialize message fields from a packet.
bfr | stream of bytes (packet) |
len | length of the byte stream. |
Implements DUNE::IMC::Message.
References ctrl_imp, DUNE::IMC::deserialize(), dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, ss_x, ss_y, ss_z, virt_err_x, virt_err_y, and virt_err_z.
|
virtual |
Compare fields for equality.
[in] | other | message to compare. |
Reimplemented from DUNE::IMC::Message.
References ctrl_imp, dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, ss_x, ss_y, ss_z, virt_err_x, virt_err_y, and virt_err_z.
|
virtual |
Output the message fields (excluding header) in JSON format.
os | output stream. |
indent_level | number of indentation spaces. |
Reimplemented from DUNE::IMC::Message.
References ctrl_imp, dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, ss_x, ss_y, ss_z, DUNE::IMC::toJSON(), virt_err_x, virt_err_y, and virt_err_z.
|
inlinevirtual |
Get the fixed amount of bytes required to properly serialize this message (variable length fields are not included).
Reimplemented from DUNE::IMC::Message.
|
inlinevirtual |
Retrieve message's identification number.
Implements DUNE::IMC::Message.
References getIdStatic().
|
inlinestatic |
Referenced by getId().
|
inlinevirtual |
|
inlinevirtual |
Get the variable amount of bytes required to properly serialize this message (only the variable fields are included).
Reimplemented from DUNE::IMC::Message.
References DUNE::IMC::getSerializationSize(), and s_id.
|
virtual |
Deserialize message fields from a packet, swapping the byte order.
bfr | stream of bytes (packet) |
len | length of the byte stream. |
Implements DUNE::IMC::Message.
References ctrl_imp, dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, DUNE::IMC::reverseDeserialize(), rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, ss_x, ss_y, ss_z, virt_err_x, virt_err_y, and virt_err_z.
|
virtual |
Implements DUNE::IMC::Message.
References ctrl_imp, dist, err, err_x, err_y, err_z, rel_dir_x, rel_dir_y, rel_dir_z, rf_err_vx, rf_err_vy, rf_err_vz, rf_err_x, rf_err_y, rf_err_z, s_id, DUNE::IMC::serialize(), ss_x, ss_y, ss_z, virt_err_x, virt_err_y, and virt_err_z.
|
virtual |
Validate the message's contents.
Implements DUNE::IMC::Message.
fp32_t DUNE::IMC::RelativeState::ctrl_imp |
Control Importance.
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::dist |
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::err |
Position Error.
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::err_x |
X Position Error (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::err_y |
Y Position Error (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::err_z |
Z Position Error (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rel_dir_x |
Relative Direction X (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rel_dir_y |
Relative Direction Y (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rel_dir_z |
Relative Direction Z (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_vx |
X Velocity Error In Relative Frame (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_vy |
Y Velocity Error In Relative Frame (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_vz |
Z Velocity Error In Relative Frame (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_x |
X Position Error In Relative Frame (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_y |
Y Position Error In Relative Frame (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::rf_err_z |
Z Position Error In Relative Frame (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
std::string DUNE::IMC::RelativeState::s_id |
System Identifier.
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), getVariableSerializationSize(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::ss_x |
X Convergence Deviation (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::ss_y |
Y Convergence Deviation (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::ss_z |
Z Convergence Deviation (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::virt_err_x |
X Virtual Error (North).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::virt_err_y |
Y Virtual Error (East).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
fp32_t DUNE::IMC::RelativeState::virt_err_z |
Z Virtual Error (Down).
Referenced by clear(), deserializeFields(), fieldsEqual(), fieldsToJSON(), reverseDeserializeFields(), and serializeFields().
