DUNE: Uniform Navigational Environment
2016.09.0
|
Public Member Functions | |
Task (const std::string &name, Tasks::Context &ctx) | |
void | onActivation (void) |
void | onDeactivation (void) |
void | onConnectionTimeout (void) |
double | applyScale (int value) |
void | onRemoteActions (const IMC::RemoteActions *msg) |
void | actuate (void) |
Public Member Functions inherited from DUNE::Control::BasicRemoteOperation | |
BasicRemoteOperation (const std::string &name, Tasks::Context &ctx) | |
virtual | ~BasicRemoteOperation (void) |
void | consume (const IMC::RemoteActions *message) |
void | consume (const IMC::RemoteActionsRequest *message) |
void | consume (const IMC::ControlLoops *message) |
void | consume (const IMC::Teleoperation *message) |
Public Member Functions inherited from DUNE::Tasks::Periodic | |
Periodic (const std::string &name, Context &ctx) | |
virtual | ~Periodic (void) |
void | setFrequency (double freq) |
double | getFrequency (void) const |
double | getRunTime (void) const |
unsigned | getRunCount (void) const |
Public Member Functions inherited from DUNE::Tasks::Task | |
Task (const std::string &name, Context &context) | |
virtual | ~Task (void) |
const char * | getName (void) const |
const char * | getSystemName (void) const |
unsigned int | getSystemId (void) const |
unsigned int | getEntityId (void) const |
unsigned int | resolveEntity (const std::string &label) const |
std::string | resolveEntity (unsigned int id) const |
DebugLevel | getDebugLevel (void) const |
uint16_t | getActivationTime (void) const |
uint16_t | getDeactivationTime (void) const |
unsigned int | resolveSystemName (const std::string &name) const |
const char * | resolveSystemId (unsigned int id) const |
void | loadConfig (void) |
void | setPriority (unsigned int value) |
unsigned int | getPriority (void) const |
void | inf (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void | war (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void | err (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void | cri (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void | debug (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void | trace (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void void | spew (const char *format,...) DUNE_PRINTF_FORMAT(2 |
void void void void void void void void | dispatch (IMC::Message *msg, unsigned int flags=0) |
void | dispatch (IMC::Message &msg, unsigned int flags=0) |
void | dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0) |
void | receive (const IMC::Message *msg) |
void | reserveEntities (void) |
void | resolveEntities (void) |
void | acquireResources (void) |
void | releaseResources (void) |
void | initializeResources (void) |
void | updateParameters (bool act_deact=true) |
void | writeParamsXML (std::ostream &os) const |
const char * | getEntityLabel (void) const |
void | setEntityLabel (const std::string &label) |
Public Member Functions inherited from DUNE::Tasks::AbstractTask | |
AbstractTask (void) | |
virtual | ~AbstractTask (void) |
Public Member Functions inherited from DUNE::Concurrency::Thread | |
Thread (void) | |
virtual | ~Thread (void) |
int | getProcessorUsage (void) |
Public Member Functions inherited from DUNE::Concurrency::Runnable | |
Runnable (void) | |
virtual | ~Runnable (void) |
void | start (void) |
void | stop (void) |
void | join (void) |
void | stopAndJoin (void) |
void | setPriority (Scheduler::Policy policy, unsigned priority) |
unsigned | getPriority (void) |
State | getState (void) |
bool | isCreated (void) |
bool | isStopping (void) |
bool | isRunning (void) |
bool | isStarting (void) |
bool | isDead (void) |
Public Attributes | |
IMC::SetThrusterActuation | m_thrust [2] |
Arguments | m_args |
double | m_speed |
double | m_heading |
Additional Inherited Members | |
Public Types inherited from DUNE::Concurrency::Runnable | |
enum | State { StateStarting, StateRunning, StateStopping, StateDead, StateUnknown } |
Protected Member Functions inherited from DUNE::Control::BasicRemoteOperation | |
void | addActionButton (const std::string &action) |
void | addActionAxis (const std::string &action) |
void | setConnectionTimeout (const float tout) |
virtual void | onRemoteActions (const IMC::RemoteActions *message) |
virtual void | onConnectionResumed (void) |
virtual void | onResourceInitialization (void) |
void | enableControlLoops (uint32_t mask) |
void | disableControlLoops (uint32_t mask) |
Protected Member Functions inherited from DUNE::Tasks::Task | |
void | setEntityState (IMC::EntityState::StateEnum state, Status::Code code) |
void | setEntityState (IMC::EntityState::StateEnum state, const std::string &description) |
IMC::EntityState::StateEnum | getEntityState (void) const |
unsigned int | reserveEntity (const std::string &label) |
template<typename E > | |
E * | reserveEntity (const std::string &label) |
bool | stopping (void) |
bool | isActive (void) const |
bool | isActivating (void) const |
bool | isDeactivating (void) const |
void | waitForMessages (double timeout) |
void | consumeMessages (void) |
template<typename T > | |
Parameter & | param (const std::string &name, T &var) |
template<typename Y , typename T > | |
Parameter & | param (const std::string &name, T &var) |
template<typename T > | |
bool | paramChanged (T &var) |
void | paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false) |
void | setParamSectionEditor (const std::string &name) |
template<typename M , typename T > | |
void | bind (T *task_obj, void(T::*consumer)(const M *)=&T::consume) |
template<typename T > | |
void | bind (T *task_obj, const std::vector< uint32_t > &list) |
template<typename T , typename M > | |
void | bind (T *task_obj, const std::vector< uint32_t > &list, void(T::*consumer)(const M *)=&T::consume) |
template<typename T > | |
void | bind (T *task_obj, const std::vector< std::string > &list) |
void | requestActivation (void) |
void | requestDeactivation (void) |
void | activate (void) |
void | activationFailed (const std::string &reason) |
void | deactivate (void) |
void | deactivationFailed (const std::string &reason) |
virtual bool | onWriteParamsXML (std::ostream &os) const |
virtual void | onEntityReservation (void) |
virtual void | onEntityResolution (void) |
virtual void | onReportEntityState (void) |
virtual void | onResourceAcquisition (void) |
virtual void | onResourceRelease (void) |
virtual void | onUpdateParameters (void) |
virtual void | onRequestActivation (void) |
virtual void | onRequestDeactivation (void) |
virtual void | onQueryEntityParameters (const IMC::QueryEntityParameters *msg) |
virtual void | onSetEntityParameters (const IMC::SetEntityParameters *msg) |
virtual void | onPushEntityParameters (const IMC::PushEntityParameters *msg) |
virtual void | onPopEntityParameters (const IMC::PopEntityParameters *msg) |
Protected Member Functions inherited from DUNE::Concurrency::Thread | |
void | startImpl (void) |
void | stopImpl (void) |
void | joinImpl (void) |
void | setPriorityImpl (Scheduler::Policy policy, unsigned priority) |
unsigned | getPriorityImpl (void) |
Protected Attributes inherited from DUNE::Tasks::Task | |
Context & | m_ctx |
std::vector < Entities::BasicEntity * > | m_entities |
|
inline |
|
inlinevirtual |
Reimplemented from DUNE::Control::BasicRemoteOperation.
References DUNE::Tasks::Task::debug(), DUNE::Tasks::Task::dispatch(), and m_thrust.
Referenced by onActivation(), onConnectionTimeout(), and onDeactivation().
|
inline |
References m_args, and Control::ASV::RemoteOperation::Arguments::scale.
Referenced by onRemoteActions().
|
inlinevirtual |
Called when the task starts/resumes normal execution.
Reimplemented from DUNE::Tasks::Task.
|
inlinevirtual |
Reimplemented from DUNE::Control::BasicRemoteOperation.
|
inlinevirtual |
Called when the task stops normal execution and enters an idleness state.
Reimplemented from DUNE::Tasks::Task.
|
inline |
References applyScale(), m_heading, m_speed, and m_thrust.
Arguments Control::ASV::RemoteOperation::Task::m_args |
Task arguments.
Referenced by applyScale(), and Task().
double Control::ASV::RemoteOperation::Task::m_heading |
Referenced by onActivation(), onConnectionTimeout(), onDeactivation(), onRemoteActions(), and Task().
double Control::ASV::RemoteOperation::Task::m_speed |
Referenced by onActivation(), onConnectionTimeout(), onDeactivation(), onRemoteActions(), and Task().
IMC::SetThrusterActuation Control::ASV::RemoteOperation::Task::m_thrust[2] |
Motor commands.
Referenced by actuate(), onActivation(), onConnectionTimeout(), onDeactivation(), onRemoteActions(), and Task().
