DUNE::IMC::DesiredPath Class Reference

Detailed Description

Desired Path.

Public Types

Public Member Functions

 DesiredPath (void)

DesiredPath * clone (void) const

void clear (void)

bool fieldsEqual (const Message &msg__) const

int validate (void) const

uint8_t * serializeFields (uint8_t *bfr__) const

uint16_t deserializeFields (const uint8_t *bfr__, uint16_t size__)

uint16_t reverseDeserializeFields (const uint8_t *bfr__, uint16_t size__)

uint16_t getId (void) const

const char * getName (void) const

unsigned getFixedSerializationSize (void) const

void fieldsToJSON (std::ostream &os__, unsigned nindent__) const

- Public Member Functions inherited from DUNE::IMC::Message
 Message (void)

virtual ~Message (void)

double setTimeStamp (double ts)

double setTimeStamp (void)

double getTimeStamp (void) const

uint16_t getSource (void) const

void setSource (uint16_t src)

uint8_t getSourceEntity (void) const

void setSourceEntity (uint8_t src_ent)

uint16_t getDestination (void) const

void setDestination (uint16_t dst)

uint8_t getDestinationEntity (void) const

void setDestinationEntity (uint8_t dst_ent)

virtual uint16_t getSubId (void) const

virtual void setSubId (uint16_t subid)

virtual fp64_t getValueFP (void) const

virtual void setValueFP (fp64_t val)

unsigned getSerializationSize (void) const

unsigned getPayloadSerializationSize (void) const

virtual unsigned getVariableSerializationSize (void) const

void toJSON (std::ostream &os) const

void toText (std::ostream &os) const

bool operator== (const Message &other) const

bool operator!= (const Message &other) const


Static Public Member Functions

static uint16_t getIdStatic (void)


Public Attributes

uint32_t path_ref

fp64_t start_lat

fp64_t start_lon

fp32_t start_z

uint8_t start_z_units

fp64_t end_lat

fp64_t end_lon

fp32_t end_z

uint8_t end_z_units

fp32_t speed

uint8_t speed_units

fp32_t lradius

uint8_t flags


Additional Inherited Members

- Protected Member Functions inherited from DUNE::IMC::Message
virtual void setTimeStampNested (double value)

virtual void setSourceNested (uint16_t value)

virtual void setSourceEntityNested (uint8_t value)

virtual void setDestinationNested (uint16_t value)

virtual void setDestinationEntityNested (uint8_t value)

- Protected Attributes inherited from DUNE::IMC::Message
Header m_header


Member Enumeration Documentation

enum DUNE::IMC::DesiredPath::FlagsBits

Flags.

Enumerator
FL_START

Start Point.

FL_DIRECT

Direct.

FL_NO_Z

No Altitude/Depth control.

FL_3DTRACK

3D Tracking.

FL_CCLOCKW

Counter-Clockwise loiter.

FL_LOITER_CURR

Loiter from current position.

FL_TAKEOFF

Takeoff.

FL_LAND

Land.

Constructor & Destructor Documentation

DUNE::IMC::DesiredPath::DesiredPath ( void  )

References DUNE::IMC::EntityState::clear(), DUNE::IMC::Message::m_header, and DUNE::IMC::Header::mgid.

Member Function Documentation

void DUNE::IMC::DesiredPath::clear ( void  )
virtual

Reset message's fields.

Implements DUNE::IMC::Message.

References DUNE::IMC::EntityState::flags.

Referenced by DUNE::Maneuvers::Elevate::Elevate().

DesiredPath* DUNE::IMC::DesiredPath::clone ( void  ) const
inlinevirtual

Retrieve a copy of the message.

Returns
message copy.

Implements DUNE::IMC::Message.

References DUNE::IMC::EntityState::clear(), DUNE::IMC::EntityState::deserializeFields(), DUNE::IMC::EntityState::fieldsEqual(), DUNE::IMC::EntityState::reverseDeserializeFields(), DUNE::IMC::EntityState::serializeFields(), and DUNE::IMC::EntityState::validate().

uint16_t DUNE::IMC::DesiredPath::deserializeFields ( const uint8_t *  bfr,
uint16_t  len
)
virtual

Deserialize message fields from a packet.

Parameters
bfrstream of bytes (packet)
lenlength of the byte stream.
Returns
number of bytes processed.

Implements DUNE::IMC::Message.

References DUNE::IMC::deserialize(), and DUNE::IMC::EntityState::flags.

bool DUNE::IMC::DesiredPath::fieldsEqual ( const Message &  other) const
virtual

Compare fields for equality.

Parameters
[in]othermessage to compare.
Returns
true if fields are equal, false otherwise.

Reimplemented from DUNE::IMC::Message.

References end_lat, end_lon, end_z, end_z_units, DUNE::IMC::EntityState::flags, flags, lradius, path_ref, speed, speed_units, start_lat, start_lon, start_z, and start_z_units.

void DUNE::IMC::DesiredPath::fieldsToJSON ( std::ostream &  os,
unsigned  indent_level
) const
virtual

Output the message fields (excluding header) in JSON format.

Parameters
osoutput stream.
indent_levelnumber of indentation spaces.

Reimplemented from DUNE::IMC::Message.

References DUNE::IMC::EntityState::flags, and DUNE::IMC::toJSON().

unsigned DUNE::IMC::DesiredPath::getFixedSerializationSize ( void  ) const
inlinevirtual

Get the fixed amount of bytes required to properly serialize this message (variable length fields are not included).

Returns
amount of variable bytes required to serialize the message.

Reimplemented from DUNE::IMC::Message.

References DUNE::IMC::EntityState::fieldsToJSON().

uint16_t DUNE::IMC::DesiredPath::getId ( void  ) const
inlinevirtual

Retrieve message's identification number.

Returns
message's identification number.

Implements DUNE::IMC::Message.

References getIdStatic().

static uint16_t DUNE::IMC::DesiredPath::getIdStatic ( void  )
inlinestatic

Referenced by getId().

const char* DUNE::IMC::DesiredPath::getName ( void  ) const
inlinevirtual

Retrieve message's name.

Returns
message's name.

Implements DUNE::IMC::Message.

uint16_t DUNE::IMC::DesiredPath::reverseDeserializeFields ( const uint8_t *  bfr,
uint16_t  len
)
virtual

Deserialize message fields from a packet, swapping the byte order.

Parameters
bfrstream of bytes (packet)
lenlength of the byte stream.
Returns
number of bytes processed.

Implements DUNE::IMC::Message.

References DUNE::IMC::deserialize(), DUNE::IMC::EntityState::flags, and DUNE::IMC::reverseDeserialize().

uint8_t * DUNE::IMC::DesiredPath::serializeFields ( uint8_t *  bfr__) const
virtual

Implements DUNE::IMC::Message.

References DUNE::IMC::EntityState::flags, and DUNE::IMC::serialize().

int DUNE::IMC::DesiredPath::validate ( void  ) const
virtual

Validate the message's contents.

Returns
negative value in case of a valid message or a positive value indicating the position of the invalid message field.

Implements DUNE::IMC::Message.

Member Data Documentation

fp64_t DUNE::IMC::DesiredPath::end_lat

End Point – WGS84 Latitude.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::VehicleFormation::consume(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), and DUNE::Maneuvers::StationKeep::StationKeep().

fp64_t DUNE::IMC::DesiredPath::end_lon

End Point – WGS-84 Longitude.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::VehicleFormation::consume(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), and DUNE::Maneuvers::StationKeep::StationKeep().

fp32_t DUNE::IMC::DesiredPath::end_z

End Point – Z Reference.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::VehicleFormation::consume(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), DUNE::Maneuvers::StationKeep::StationKeep(), and DUNE::Maneuvers::Elevate::update().

uint8_t DUNE::IMC::DesiredPath::end_z_units

End Point – Z Units.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), DUNE::Maneuvers::StationKeep::StationKeep(), and DUNE::Maneuvers::Elevate::update().

uint8_t DUNE::IMC::DesiredPath::flags

Flags.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), and DUNE::Maneuvers::Elevate::update().

fp32_t DUNE::IMC::DesiredPath::lradius

Loiter – Radius.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), and DUNE::Maneuvers::FigureEight::FigureEight().

uint32_t DUNE::IMC::DesiredPath::path_ref

Path Reference.

Referenced by DUNE::Control::PathController::consume(), DUNE::Maneuvers::Maneuver::dispatch(), and fieldsEqual().

fp32_t DUNE::IMC::DesiredPath::speed

Speed.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::VehicleFormation::consume(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredSpeed(), DUNE::Maneuvers::VehicleFormation::desiredSpeed(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), and DUNE::Maneuvers::StationKeep::StationKeep().

uint8_t DUNE::IMC::DesiredPath::speed_units

Speed Units.

Referenced by DUNE::Maneuvers::Circular::Circular(), DUNE::Maneuvers::VehicleFormation::consume(), DUNE::Maneuvers::FollowTrajectory::consume(), DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredSpeed(), DUNE::Maneuvers::VehicleFormation::desiredSpeed(), DUNE::Maneuvers::Elevate::Elevate(), fieldsEqual(), DUNE::Maneuvers::FigureEight::FigureEight(), and DUNE::Maneuvers::StationKeep::StationKeep().

fp64_t DUNE::IMC::DesiredPath::start_lat

Start Point – Latitude WGS-84.

Referenced by DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), fieldsEqual(), and DUNE::Maneuvers::FigureEight::FigureEight().

fp64_t DUNE::IMC::DesiredPath::start_lon

Start Point – WGS-84 Longitude.

Referenced by DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), fieldsEqual(), and DUNE::Maneuvers::FigureEight::FigureEight().

fp32_t DUNE::IMC::DesiredPath::start_z

Start Point – Z Reference.

Referenced by DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), DUNE::Maneuvers::VehicleFormation::desiredPath(), and fieldsEqual().

uint8_t DUNE::IMC::DesiredPath::start_z_units

Start Point – Z Units.

Referenced by DUNE::Control::PathController::consume(), DUNE::Maneuvers::FollowTrajectory::desiredPath(), and fieldsEqual().

Collaboration diagram for DUNE::IMC::DesiredPath:
Collaboration graph
