DUNE: Uniform Navigational Environment  2019.02.1
List of all members | Public Member Functions | Public Attributes
Control::UAV::LOS::Task Struct Reference

Public Member Functions

 Task (const std::string &name, Tasks::Context &ctx)

void onUpdateParameters (void)

void onPathActivation (void)

void consume (const IMC::IndicatedSpeed *airspeed)

void step (const IMC::EstimatedState &state, const TrackingState &ts)

- Public Member Functions inherited from DUNE::Control::ProxyPathController
 ProxyPathController (const std::string &name, Tasks::Context &ctx)

virtual ~ProxyPathController (void)

void onEntityResolution (void)

virtual bool sourceFilter (const IMC::EstimatedState *es)

- Public Member Functions inherited from DUNE::Control::PathController
 PathController (std::string name, Tasks::Context &ctx)

virtual ~PathController (void)

void onEntityReservation (void)

void consume (const IMC::Brake *brake)

void consume (const IMC::EstimatedState *es)

void consume (const IMC::ControlLoops *cl)

void consume (const IMC::DesiredPath *dp)

void consume (const IMC::NavigationUncertainty *nu)

void consume (const IMC::Distance *dist)

void consume (const IMC::DesiredZ *zref)

void consume (const IMC::DesiredSpeed *dspeed)

virtual void onResourceInitialization (void)

virtual void onResourceRelease (void)

virtual void onPathDeactivation (void)

virtual void onPathStartup (const IMC::EstimatedState &state, const TrackingState &ts)

virtual void step (const IMC::EstimatedState &state, const TrackingState &ts)=0

virtual void loiter (const IMC::EstimatedState &state, const TrackingState &ts)

virtual bool hasSpecificZControl (void) const

virtual double getEta (const TrackingState &ts)

float getSpeed (void)

float getTimeFactor (void)

void signalError (const std::string &msg)

void enableControlLoops (uint32_t mask)

void disableControlLoops (uint32_t mask)

void onMain (void)

- Public Member Functions inherited from DUNE::Tasks::Task
 Task (const std::string &name, Context &context)

virtual ~Task (void)

const char * getName (void) const

const char * getSystemName (void) const

unsigned int getSystemId (void) const

unsigned int getEntityId (void) const

unsigned int resolveEntity (const std::string &label) const

std::string resolveEntity (unsigned int id) const

DebugLevel getDebugLevel (void) const

uint16_t getActivationTime (void) const

uint16_t getDeactivationTime (void) const

unsigned int resolveSystemName (const std::string &name) const

const char * resolveSystemId (unsigned int id) const

void loadConfig (void)

void setPriority (unsigned int value)

unsigned int getPriority (void) const

void inf (const char *format,...) DUNE_PRINTF_FORMAT(2

void void war (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void err (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void cri (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void debug (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void trace (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void spew (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void void dispatch (IMC::Message *msg, unsigned int flags=0)

void dispatch (IMC::Message &msg, unsigned int flags=0)

void dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0)

void receive (const IMC::Message *msg)

void reserveEntities (void)

void resolveEntities (void)

void acquireResources (void)

void releaseResources (void)

void initializeResources (void)

void updateParameters (bool act_deact=true)

void writeParamsXML (std::ostream &os) const

const char * getEntityLabel (void) const

void setEntityLabel (const std::string &label)

- Public Member Functions inherited from DUNE::Tasks::AbstractTask
 AbstractTask (void)

virtual ~AbstractTask (void)

- Public Member Functions inherited from DUNE::Concurrency::Thread
 Thread (void)

virtual ~Thread (void)

int getProcessorUsage (void)

- Public Member Functions inherited from DUNE::Concurrency::Runnable
 Runnable (void)

virtual ~Runnable (void)

void start (void)

void stop (void)

void join (void)

void stopAndJoin (void)

void setPriority (Scheduler::Policy policy, unsigned priority)

unsigned getPriority (void)

State getState (void)

bool isCreated (void)

bool isStopping (void)

bool isRunning (void)

bool isStarting (void)

bool isDead (void)


Public Attributes

Arguments m_args

IMC::DesiredRoll m_bank

double m_airspeed


Additional Inherited Members

- Public Types inherited from DUNE::Concurrency::Runnable
- Protected Member Functions inherited from DUNE::Tasks::Task
void setEntityState (IMC::EntityState::StateEnum state, Status::Code code)

void setEntityState (IMC::EntityState::StateEnum state, const std::string &description)

IMC::EntityState::StateEnum getEntityState (void) const

unsigned int reserveEntity (const std::string &label)

template<typename E >
E * reserveEntity (const std::string &label)

Entities::BasicEntity * getLocalEntity (const std::string &label)

bool stopping (void)

bool isActive (void) const

bool isActivating (void) const

bool isDeactivating (void) const

void waitForMessages (double timeout)

void consumeMessages (void)

template<typename T >
Parameter & param (const std::string &name, T &var)

template<typename Y , typename T >
Parameter & param (const std::string &name, T &var)

template<typename T >
bool paramChanged (T &var)

void paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false)

void setParamSectionEditor (const std::string &name)

template<typename M , typename T >
void bind (T *task_obj, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< uint32_t > &list)

template<typename T , typename M >
void bind (T *task_obj, const std::vector< uint32_t > &list, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< std::string > &list)

void requestActivation (void)

void requestDeactivation (void)

void activate (void)

void activationFailed (const std::string &reason)

void deactivate (void)

void deactivationFailed (const std::string &reason)

virtual bool onWriteParamsXML (std::ostream &os) const

virtual void onReportEntityState (void)

virtual void onResourceAcquisition (void)

virtual void onRequestActivation (void)

virtual void onRequestDeactivation (void)

virtual void onQueryEntityParameters (const IMC::QueryEntityParameters *msg)

virtual void onSetEntityParameters (const IMC::SetEntityParameters *msg)

virtual void onPushEntityParameters (const IMC::PushEntityParameters *msg)

virtual void onPopEntityParameters (const IMC::PopEntityParameters *msg)

- Protected Member Functions inherited from DUNE::Concurrency::Thread
void startImpl (void)

void stopImpl (void)

void joinImpl (void)

void setPriorityImpl (Scheduler::Policy policy, unsigned priority)

unsigned getPriorityImpl (void)

- Protected Attributes inherited from DUNE::Tasks::Task
Context & m_ctx

std::vector< Entities::BasicEntity * > m_entities


Constructor & Destructor Documentation

Control::UAV::LOS::Task::Task ( const std::string &  name,
Tasks::Context &  ctx
)
inline

References Control::UAV::LOS::Arguments::la_gain, Control::UAV::LOS::Arguments::max_bank, Control::UAV::LOS::Arguments::tr_gain, and Control::UAV::LOS::Arguments::use_controller.

Member Function Documentation

void Control::UAV::LOS::Task::consume ( const IMC::IndicatedSpeed *  airspeed)
inline
void Control::UAV::LOS::Task::onPathActivation ( void  )
inlinevirtual

Handler for path control activation.

This is called when path control is activated. By default it does nothing.

Reimplemented from DUNE::Control::PathController.

References Control::UAV::LOS::Arguments::use_controller.

void Control::UAV::LOS::Task::onUpdateParameters ( void  )
inlinevirtual

Handler for parameter updates.

This can be overriden but in that case this parent class implementation MUST be called.

Reimplemented from DUNE::Control::PathController.

References Control::UAV::LOS::Arguments::la_gain, and Control::UAV::LOS::Arguments::max_bank.

void Control::UAV::LOS::Task::step ( const IMC::EstimatedState &  state,
const TrackingState &  ts
)
inline

References Control::UAV::LOS::Arguments::la_gain, Control::UAV::LOS::Arguments::max_bank, Control::UAV::LOS::Arguments::tr_gain, DUNE::Control::PathController::TrackingState::track_pos, DUNE::Control::PathController::TrackingState::track_vel, DUNE::Math::trimValue(), Control::UAV::LOS::Arguments::use_controller, DUNE::Control::PathController::TrackingState::TrackCoord::x, and DUNE::Control::PathController::TrackingState::TrackCoord::y.

Member Data Documentation

double Control::UAV::LOS::Task::m_airspeed
Arguments Control::UAV::LOS::Task::m_args
IMC::DesiredRoll Control::UAV::LOS::Task::m_bank
Collaboration diagram for Control::UAV::LOS::Task:
Collaboration graph
