DUNE: Uniform Navigational Environment  2019.02.1
List of all members | Public Member Functions | Public Attributes
Control::Path::PurePursuit::Task Struct Reference

Public Member Functions

 Task (const std::string &name, Tasks::Context &ctx)

void onUpdateParameters (void)

void onEntityReservation (void)

void onPathActivation (void)

void onPathDeactivation (void)

void step (const IMC::EstimatedState &state, const TrackingState &ts)

- Public Member Functions inherited from DUNE::Control::PathController
 PathController (std::string name, Tasks::Context &ctx)

virtual ~PathController (void)

void onEntityReservation (void)

void consume (const IMC::Brake *brake)

void consume (const IMC::EstimatedState *es)

void consume (const IMC::ControlLoops *cl)

void consume (const IMC::DesiredPath *dp)

void consume (const IMC::NavigationUncertainty *nu)

void consume (const IMC::Distance *dist)

void consume (const IMC::DesiredZ *zref)

void consume (const IMC::DesiredSpeed *dspeed)

virtual void onResourceInitialization (void)

virtual void onResourceRelease (void)

virtual void onPathStartup (const IMC::EstimatedState &state, const TrackingState &ts)

virtual void step (const IMC::EstimatedState &state, const TrackingState &ts)=0

virtual void loiter (const IMC::EstimatedState &state, const TrackingState &ts)

virtual bool hasSpecificZControl (void) const

virtual double getEta (const TrackingState &ts)

float getSpeed (void)

float getTimeFactor (void)

void signalError (const std::string &msg)

void enableControlLoops (uint32_t mask)

void disableControlLoops (uint32_t mask)

virtual bool sourceFilter (const IMC::EstimatedState *es)

void onMain (void)

- Public Member Functions inherited from DUNE::Tasks::Task
 Task (const std::string &name, Context &context)

virtual ~Task (void)

const char * getName (void) const

const char * getSystemName (void) const

unsigned int getSystemId (void) const

unsigned int getEntityId (void) const

unsigned int resolveEntity (const std::string &label) const

std::string resolveEntity (unsigned int id) const

DebugLevel getDebugLevel (void) const

uint16_t getActivationTime (void) const

uint16_t getDeactivationTime (void) const

unsigned int resolveSystemName (const std::string &name) const

const char * resolveSystemId (unsigned int id) const

void loadConfig (void)

void setPriority (unsigned int value)

unsigned int getPriority (void) const

void inf (const char *format,...) DUNE_PRINTF_FORMAT(2

void void war (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void err (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void cri (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void debug (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void trace (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void spew (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void void dispatch (IMC::Message *msg, unsigned int flags=0)

void dispatch (IMC::Message &msg, unsigned int flags=0)

void dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0)

void receive (const IMC::Message *msg)

void reserveEntities (void)

void resolveEntities (void)

void acquireResources (void)

void releaseResources (void)

void initializeResources (void)

void updateParameters (bool act_deact=true)

void writeParamsXML (std::ostream &os) const

const char * getEntityLabel (void) const

void setEntityLabel (const std::string &label)

- Public Member Functions inherited from DUNE::Tasks::AbstractTask
 AbstractTask (void)

virtual ~AbstractTask (void)

- Public Member Functions inherited from DUNE::Concurrency::Thread
 Thread (void)

virtual ~Thread (void)

int getProcessorUsage (void)

- Public Member Functions inherited from DUNE::Concurrency::Runnable
 Runnable (void)

virtual ~Runnable (void)

void start (void)

void stop (void)

void join (void)

void stopAndJoin (void)

void setPriority (Scheduler::Policy policy, unsigned priority)

unsigned getPriority (void)

State getState (void)

bool isCreated (void)

bool isStopping (void)

bool isRunning (void)

bool isStarting (void)

bool isDead (void)


Public Attributes

IMC::DesiredHeading m_heading


Additional Inherited Members

- Public Types inherited from DUNE::Concurrency::Runnable
- Protected Member Functions inherited from DUNE::Tasks::Task
void setEntityState (IMC::EntityState::StateEnum state, Status::Code code)

void setEntityState (IMC::EntityState::StateEnum state, const std::string &description)

IMC::EntityState::StateEnum getEntityState (void) const

unsigned int reserveEntity (const std::string &label)

template<typename E >
E * reserveEntity (const std::string &label)

Entities::BasicEntity * getLocalEntity (const std::string &label)

bool stopping (void)

bool isActive (void) const

bool isActivating (void) const

bool isDeactivating (void) const

void waitForMessages (double timeout)

void consumeMessages (void)

template<typename T >
Parameter & param (const std::string &name, T &var)

template<typename Y , typename T >
Parameter & param (const std::string &name, T &var)

template<typename T >
bool paramChanged (T &var)

void paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false)

void setParamSectionEditor (const std::string &name)

template<typename M , typename T >
void bind (T *task_obj, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< uint32_t > &list)

template<typename T , typename M >
void bind (T *task_obj, const std::vector< uint32_t > &list, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< std::string > &list)

void requestActivation (void)

void requestDeactivation (void)

void activate (void)

void activationFailed (const std::string &reason)

void deactivate (void)

void deactivationFailed (const std::string &reason)

virtual bool onWriteParamsXML (std::ostream &os) const

virtual void onEntityResolution (void)

virtual void onReportEntityState (void)

virtual void onResourceAcquisition (void)

virtual void onRequestActivation (void)

virtual void onRequestDeactivation (void)

virtual void onQueryEntityParameters (const IMC::QueryEntityParameters *msg)

virtual void onSetEntityParameters (const IMC::SetEntityParameters *msg)

virtual void onPushEntityParameters (const IMC::PushEntityParameters *msg)

virtual void onPopEntityParameters (const IMC::PopEntityParameters *msg)

- Protected Member Functions inherited from DUNE::Concurrency::Thread
void startImpl (void)

void stopImpl (void)

void joinImpl (void)

void setPriorityImpl (Scheduler::Policy policy, unsigned priority)

unsigned getPriorityImpl (void)

- Protected Attributes inherited from DUNE::Tasks::Task
Context & m_ctx

std::vector< Entities::BasicEntity * > m_entities


Constructor & Destructor Documentation

Control::Path::PurePursuit::Task::Task ( const std::string &  name,
Tasks::Context &  ctx
)
inline

Member Function Documentation

void Control::Path::PurePursuit::Task::onEntityReservation ( void  )
inlinevirtual

Called when the task is instructed to reserve all the entity identifiers it needs for normal execution.

See reserveEntity(). Derived classes that need to reserve entity identifiers other than that of the main entity should override this function.

Reimplemented from DUNE::Tasks::Task.

void Control::Path::PurePursuit::Task::onPathActivation ( void  )
inlinevirtual

Handler for path control activation.

This is called when path control is activated. By default it does nothing.

Reimplemented from DUNE::Control::PathController.

References DUNE::Control::PathController::enableControlLoops().

void Control::Path::PurePursuit::Task::onPathDeactivation ( void  )
inlinevirtual

Handler for path control deactivation.

This is called when path control is deactivated. By default it does nothing.

Reimplemented from DUNE::Control::PathController.

References DUNE::Control::PathController::disableControlLoops().

void Control::Path::PurePursuit::Task::onUpdateParameters ( void  )
inlinevirtual

Handler for parameter updates.

This can be overriden but in that case this parent class implementation MUST be called.

Reimplemented from DUNE::Control::PathController.

void Control::Path::PurePursuit::Task::step ( const IMC::EstimatedState &  state,
const TrackingState &  ts
)
inline

References DUNE::Control::PathController::TrackingState::cc, DUNE::Control::PathController::TrackingState::course, DUNE::Tasks::Task::dispatch(), and DUNE::Control::PathController::TrackingState::los_angle.

Member Data Documentation

IMC::DesiredHeading Control::Path::PurePursuit::Task::m_heading
Collaboration diagram for Control::Path::PurePursuit::Task:
Collaboration graph
